工业电梯 Industrial Elevator
南京红杉工业科技有限公司是Gaoli Elevator 在中国大陆建材行业的独家战略合作伙伴。
Our Company is Gaoli Elevator’s exclusive strategic partner in the building materials industry in mainland China.
Industrial elevators provide a durable and reliable vertical access solution for industrial facilities. Industrial elevators efficiently transport passengers and materials to critical elevated areas on industrial sites eliminating the need for stair climbing, enhancing safety and productivity.
工业电梯在复杂环境下，为工业设施提供耐用可靠的垂直通道解决方案，电梯可高效地将乘客和物料运送到工业场地上的关键高架区域，无需爬楼梯，从而提高安全性和生产率。
如果您需要更多案例以及应用信息，请联系我们（Contact us）。
If you need more cases and application information, please Contact us.
We will provide BIM support in your project design.
Case study with google docs：https://drive.google.com/file/d/1Ul25clFNBpBXTpN_BL1Eo_WaaLKIZ7I-/view?usp=sharing
Industrial elevators for plants In Phillippines 2022
| PREHEATER LINE 1 ELEVATOR | Speed: | 54m/min |
| Project address: Philippines Apo plant | Control level: Remark: | Unmanned control system. Empty Cabins can be called |
| Product info | up to floors by floor buttons. | |
| Model No.: SC200GN | Other: | Added with intercom |
| Cabin size: 2.4*1.5*2.35m | system, which works as the phone between floors and | |
| Capacity: 2ton | the cabin. | |
| Total mast height: 86m | ||
| Number of floors: 8 floors (stops) |
Cemex industrial elevator
————————————————————————————————————————————————————-
Industrial elevator for plants In Costa Reca 2017
| PREHEATER LINE ELEVATOR | Control level: | Floor selecting system. |
| Project address: Costa Rica cement plant
Product info |
Remark: | Operator is required to push number buttons in the cabin so as to drive the cabin up or down to the matching floors. |
| Model No.: SC320GN | ||
| Other: | Added with intercom system, | |
| Cabin size: 3.2*1.5*2.1m | which works as the phone
between floors and the cabin. |
|
| Capacity: 3.2ton | ||
| Total mast height: 70m | ||
| Number of floors: 5 floors (stops) | ||
| Speed: 50m/min |
Industrial elevator for plants In China 2015
| POWER PLANT ELEVATOR | Control level: | Manual control system. |
| Project address: Wuhu power plant | Remark: | Operator is required to stay in the cabin using the joystick |
| Product info | to control the cabin, there is no pre-set floor buttons. | |
| Model No.: SC200/200GS | ||
| Other: | Added with intercom system, | |
| Cabin size: 3.2*1.5*2.5m | which works as the phone
between floors and the cabin. |
|
| Capacity: 2ton | ||
| Total mast height: 260m | ||
| Number of floors: numerous floors (stops) | ||
| Speed: 96m/min |
